Before we begin, ensuring that the secret file names match the user’s name will save your time a lot. e.g john.key john.csr john.crt john.pem etc.
Content Outline —
- Generate certificates for the user.
- Create a certificate signing request (CSR).
- Sign the certificate using the cluster certificate authority.
- Create a configuration specific to the user.
- Add RBAC rules for the user or their group.
1. Generate certificates for the user.
Following command will generates an Ed25519 private key using OpenSSL.
openssl genpkey -out john.key -algorithm Ed25519
“Algorithm Ed25519 not found” If you find this error simply upgrade your openssl.
cat john.key
-----BEGIN PRIVATE KEY-----
MC4CAQAwBQYDK2VwBCIEIBDWF4uAgPnmVQ9meMtjG4cMomoq8qpfyfOZ14Ef8pYq
-----END PRIVATE KEY-----
After executing this command, OpenSSL will generate an Ed25519(which is a modern elliptic curve cryptography algorithm) private key and save it in the “john.key” file. Keep in mind that it’s crucial to protect this private key since it grants access to sensitive information or operations.
openssl req -new -key john.key -out john.csr -subj "/CN=john,/O=edit"
In this example, the Common Name (CN) is set to “john” and the Organization (O) is set to “edit”.
2. Create a certificate signing request (CSR).
For request we have to obtain the base64-encoded representation of the contents of the “john.csr” file without newline characters. This encoding is often useful for transmitting or storing binary data in a text-based format.
cat john.csr | base64 | tr -d "\n"
LS0tLS1CRUdJTiBDRVJUSUZJQ0FURSBSRVFVRVNULS0tLS0KTUlHZU1GSUNBUUF3SHpFT01Bd0dBMVVFQXd3RmFtOW9iaXd4RFRBTEJnTlZCQW9NQkdWa2FYUXdLakFGQmdNcgpaWEFESVFEbk9nYXEzSEcyMkw1dFROZ0JaQ1lHYkJiSjdXQ05BTmE2aWhsNll0NWFkNkFBTUFVR0F5dGxjQU5CCkFPeVJaZlpKY2c3eE90eHBjUmFqZmlySk9WcVkvaE9CQldneEJubERFek4rbXpJRm12MkU5czNoaXBQZjBOYk8KMkNrR0pNR0NhOXJabStVRHowelhqZ009Ci0tLS0tRU5EIENFUlRJRklDQVRFIFJFUVVFU1QtLS0tLQo=
Then we will copy a CertificateSigningReques template from k8 docs. Simply copy the output from previous command & replace in .spec.request.
cat <<EOF | kubectl apply -f -
apiVersion: certificates.k8s.io/v1
kind: CertificateSigningRequest
metadata:
name: john
spec:
request: LS0tLS1CRUdJTiBDRVJUSUZJQ0FURSBSRVFVRVNULS0tLS0KTUlHZU1GSUNBUUF3SHpFT01Bd0dBMVVFQXd3RmFtOW9iaXd4RFRBTEJnTlZCQW9NQkdWa2FYUXdLakFGQmdNcgpaWEFESVFEbk9nYXEzSEcyMkw1dFROZ0JaQ1lHYkJiSjdXQ05BTmE2aWhsNll0NWFkNkFBTUFVR0F5dGxjQU5CCkFPeVJaZlpKY2c3eE90eHBjUmFqZmlySk9WcVkvaE9CQldneEJubERFek4rbXpJRm12MkU5czNoaXBQZjBOYk8KMkNrR0pNR0NhOXJabStVRHowelhqZ009Ci0tLS0tRU5EIENFUlRJRklDQVRFIFJFUVVFU1QtLS0tLQo=
signerName: kubernetes.io/kube-apiserver-client
expirationSeconds: 86400 # one day
usages:
- client auth
EOF
certificatesigningrequest.certificates.k8s.io/john created
3. Sign the certificate using the cluster certificate authority.
By executing following command, you authorize the issuance of a certificate associated with the CSR, allowing the user to use the certificate for authentication and access within the Kubernetes cluster.
kubectl certificate approve john
certificatesigningrequest.certificates.k8s.io/john approved
We can double check our user (john’s) CSR status.
kubectl describe csr/john
Name: john
Labels: <none>
Annotations: kubectl.kubernetes.io/last-applied-configuration={"apiVersion":"certificates.k8s.io/v1","kind":"CertificateSigningRequest","metadata":{"annotations":{},"name":"john"},"spec":{"expirationSeconds":86400,"request":"LS0tLS1CRUdJTiBDRVJUSUZJQ0FURSBSRVFVRVNULS0tLS0KTUlHZU1GSUNBUUF3SHpFT01Bd0dBMVVFQXd3RmFtOW9iaXd4RFRBTEJnTlZCQW9NQkdWa2FYUXdLakFGQmdNcgpaWEFESVFEbk9nYXEzSEcyMkw1dFROZ0JaQ1lHYkJiSjdXQ05BTmE2aWhsNll0NWFkNkFBTUFVR0F5dGxjQU5CCkFPeVJaZlpKY2c3eE90eHBjUmFqZmlySk9WcVkvaE9CQldneEJubERFek4rbXpJRm12MkU5czNoaXBQZjBOYk8KMkNrR0pNR0NhOXJabStVRHowelhqZ009Ci0tLS0tRU5EIENFUlRJRklDQVRFIFJFUVVFU1QtLS0tLQo=","signerName":"kubernetes.io/kube-apiserver-client","usages":["client auth"]}}
CreationTimestamp: Wed, 21 Jun 2023 14:28:59 +0000
Requesting User: system:admin
Signer: kubernetes.io/kube-apiserver-client
Requested Duration: 24h
Status: Approved,Issued
Subject:
Common Name: john,
Serial Number:
Organization: edit
Events: <none>
Please note that in production env, you’ll need the appropriate permissions and role-based access control (RBAC) privileges to execute this command successfully. But we’re here for short & quick proto, aren’t we?
4. Create a configuration specific to the user.
kubectl get csr/john -o jsonpath="{.status.certificate}" | base64 -d > john.crt
cp ~/.kube/config john-kube-config #always backup
kubectl config get-clusters
NAME
default
Now we extracts the certificate from a CertificateSigningRequest (CSR) named “john” using kubectl
and jsonpath
. The certificate is base64-decoded and saved in a file named "john.crt". Keep in mind that we only have one cluster in this case named default
.
kubectl --kubeconfig john-kube-config config set-credentials john --client-key john.key --client-certificate john.csr --embed-certs=true
User "john" set.
To set credentials for a user named “john” using a Kubernetes configuration file named “john-kube-config”. It specifies the client key, client certificate, and enables embedding of the certificates.
kubectl --kubeconfig john-kube-config config set-context john --cluster default --user john
Context "john" created.
To set a context named “john” in a Kubernetes configuration file named “john-kube-config”. It specifies the cluster default
and user john
to be associated with this context.
5. Add RBAC rules for the user or their group.
Create a Role for John to manage pods in the default namespace:
kubectl create role pod-manager --verb=create,list,get --resource=pods --namespace=default
Bind the Role with a ClusterRoleBinding:
kubectl create clusterrolebinding john-pod-manager — clusterrole=pod-manager — user=john
Verify authorization using kubectl auth can-i
:
kubectl auth can-i create deployments --namespace=default --as=john
no
kubectl auth can-i create secrets --namespace=default --as=john
no
kubectl auth can-i get pods --namespace=default --as=john
yes
Good work, we successfully create pod-manager called John. Inspire by this repo from Brendan Burns.
We still have more problems to tackle —
Key Distribution: Distributing cryptographic keys securely is essential to maintain the confidentiality and integrity of sensitive information. How do we share it? mailed? Drive or Dropbox it?
Key Expiration: Setting expiration dates for cryptographic keys is crucial for maintaining security. Regularly rotating keys helps mitigate the risk of compromised keys over time. We want the user to update the key easily but not so easily for unauthorized one.
Key Security: Protecting cryptographic keys is of utmost importance. It is important to consider industry best practices and relevant standards. Because in security context everything is vulnerable.
Key Breaches: If a key is compromised, it can lead to severe security breaches. Do we have incident response plan, or key revocation and replacement.
While the security landscape is ever-evolving and vulnerabilities can emerge, comprehensive security practices, risk assessments, and a proactive approach can significantly mitigate risks and enhance overall security. Hope it’s useful and have a good one.
